Tesla's camera tech has proven its worth, but there are some steps to setting it up correctly.

Tesla, a company already known for their disruptive tech, has one underappreciated feature that deserves mention — their built-in dashcam. Using proprietary Autopilot cameras, Tesla owners can store and record live footage at no additional cost.

  • This article comes to us courtesy of EVANNEX (which also makes aftermarket Tesla accessories). Posted by Denis Gurskiy. The opinions expressed in these articles are not necessarily our own at InsideEVs.

Source: Tesla

With this always-running, free-to-use system, Tesla owners have been able to capture some gnarly accidentsprove insurance fraud, and even help identify hit and run suspects. The Silicon Valley automaker has even added a feature dubbed "Sentry Mode" that allows the cameras to continue recording even with the vehicle off. This has led to a string of arrests as vandals and thieves keep getting caught red-handed as Tesla's cameras record their dirty deeds.

Source: Jed Franklin

The system simultaneously records from three different angles for an optimal unobstructed view of its surroundings. The three cameras, front, right repeater, and left repeater, are just three of the eight on-board cameras used to enable Tesla's Autopilot. That's right — the same cameras used to record accident footage will (eventually) enable full self-driving in the future.

For the most part, the Tesla dashcam setup is a 30-second process, but there's a few things you'll need first. A standard USB will work fine as long as it holds a minimum of 1.8 GB of storage. If it's already formatted to Fat32 or (MS-DOS (FAT) for Macs), you're ready to move on to the next step. If not, check out how to re-format down below.

However some people have reported issues with formatting their USBs through this method, but thankfully there is an alternative. You'll just need one of the many free partition managers out there. We have a video below summarizing the process, but we also have a step-by-step guide underneath if that suits you better.

 Source: EVBite

Plug your USB into your computer, open up the software, select your USB from the list drives connected to your computer, and select "format partition" and you're ready to move on to the next step.

A pop-up will display allowing you to choose which format you'd like. In order to use the Tesla dashcam, you'll need to select Fat32. Just accept and select "Apply" on the top left and you're ready to go.

There's no need to toggle anything on or off — as long as you see the red indicator on your vehicle's top right display, the system is running properly. Everything is being recorded and saved as you drive. When your USB runs out of space, the car will automatically delete and overwrite older footage. If you'd like to permanently save a clip, just tap that red indicator. That will capture the previous 10 minutes of driving and separate it into a new folder.

On the likely chance your USB is formatted properly, all you need to do is create a new folder and name it TeslaCam. Simply plug it into your Tesla's USB port and you should see a red recording indicator on your display. That's it, you're ready to go. However, if you see an X, your USB is probably not formatted properly.

While reformatting might sound complicated, it's not. With just five mouse clicks, it's a two-minute process at most. Most likely you'll be able to format your USB within windows with no problems as illustrated above.

Sentry Mode is a second feature that allows you to use the same cameras and USB to record while your car is off. Due to excess battery drainage that can occur, Sentry Mode does include a toggle switch. To enable, tap the lens icon to the right of the TeslaCam one. Additionally, you can enable the feature from within the app. Once you get back to your car the feature will disable so you'll have to re-enable with each use.

Tesla's Sentry Mode is more than just an active camera system. In addition to the camera, the feature uses the vehicle's sensors to monitor for suspicious activity. If anyone so much as leans on your car, the car's display will flash a "recording" message, notify you via phone, and save the footage. This has been used in the past (see below) in order to identify vandals and possible damage to vehicles.

Source: Teslaffinity

To view the footage, simply disconnect the USB from your car, connect it to a computer, and open one of the video files. They will be organized by date for convenience. Both features record in short one-minute intervals. Even when saved, you'll have ten minutes of footage separated into ten different files for each of the three cameras. This can be a hassle for those without any sort of editing software but there's an easy option.

Using a web-based teslacam viewer you can upload and view all three cameras side-by-side in video format. If you have any issues with it you might need to try it out on Microsoft Edge, Safari, or download this Microsoft extension. This is due to the fact that Tesla uses a video encoding format not yet implemented by other browsers.

===

An earlier version of this article appeared on EVBite. EVBite is an electric vehicle specific news site dedicated to keeping consumers up-to-date on any developments in the ever-expanding EV landscape.
