Tesla was able to consolidate and eliminate parts in its cooling system in a unique way.

In a previous article we explained how Tesla eliminated and consolidated high voltage parts in Model 3. It eliminated the battery loop heater (drive motor now used instead), combined the DC-DC converter and onboard charger into one unit, and relocated many of the parts in a central location on top of the battery (called the “penthouse”). These changes eliminated lots of wiring, cut costs of parts and decreased assembly time.

Related Content:

Tesla Model 3 Battery Can Transfer Twice The Heat Of Model S P100D

Tesla has done the exact same thing in the cooling/heating system of the Model 3.

How you ask?

Enter “Super Bottle”

Tesla likes to give names to machines and this little character is actually stamped on the bottle, which holds glycol coolant for the battery loop and the drive unit/power electronics loop.

Slide1 (8)

Photo credit Munro and Associates and Autoline After Hours via You Tube

We explained in an earlier article how these two loops operate. Tesla can run the loops separately, or they can combine the two loops together. Combining the loops allows Tesla to scavenge heat from the power electronics and drive unit to heat the battery. Hyundai uses this technique as well. GM does not. Connecting these two loops together (or not) is accomplished with a four-way valve.

What Tesla has done with super bottle is to consolidate four components onto the super bottle: the pumps for the two loops, the air conditioning chiller that cools the battery loop and the four-way valve.

Below are three screen shots that show the super bottle (courtesy of Munro and Associates and Autoline after Hours via You Tube).

Slide2 (10)

Slide3 (8)

Slide4 (6)

In the Model S and X, the components now consolidated into Mr. Super Bottle were scatted under the frunk. Each with hoses to connect said component to coolant tanks.

What do you think?

View

Comments

Fewer parts=lower cost and faster assembly.

About the only disadvantage might be repair costs if Tesla changed out the whole super bottle due to a pump failure. Hopefully, they can just detach a failed part and replace the single part if that happens.
