Everything You Ever Wanted To Know About Tesla Batteries

If you're like us, you've long had questions about the batteries that power Tesla vehicles. Now, we have answers in this first of two videos.

Everything You Ever Wanted To Know About Tesla Batteries

Domenick Yoney Domenick Yoney

By: Domenick Yoney

Aug 7, 2018 at 2:04pm ET

Add InsideEVs as a preferred source in Google

Share

Comment

You have questions, Two Bit da Vinci has answers.

One of the main reasons Tesla is where it is today is because of batteries. They attacked the problem of electric vehicle range — the traditional weak point of EVs — by choosing the most energy-dense cell available and then developed the battery pack to suit its needs. The result was a more than 200 miles of range and all the power needed to not only turn heads, but to turn an entire industry on its ear.

More about Tesla batteries.

Tesla Battery Expert's Recommendation For Maximum Battery Life - Video

Now, there's a lot to lithium batteries and they've been changing over time. If you're like us, you probably have a few questions about the batteries in assorted Tesla vehicles but haven't had the opportunity to ask. Well, today might be our lucky day as Two Bit da Vinci rides to the rescue with Part one of a two-part series that will very likely answer our questions. All you need is about a dozen minutes, so if you've got that, sit back and hit play on the video above. Enjoy!

Video description:

What do you think?

View

Comments

**NOTE* We incorrectly converted lbs to kgs in the costs. So Please go by the price per pound! Lithium = $7.50/lb, Nickel = $4.05 /lb, Manganese = $0.93 /lb, Cobalt = $36.50 / lb*

Today we are going to talk about “The Truth about Tesla’s Batteries.” If you’re thinking about a Tesla, you’ve undoubtedly heard about how cheap they are to fill up, how little maintenance they require, and with recent Model 3 Production ramp ups*, we’re on the verge of absolute Tesla ubiquity. But one of the questions that we believe keep potential buyers up at night, surrounds their battery packs. So we’ve compiled a list of all the questions we’ve received, and we’re going to break it down, step by step in this* two part video series.

First we’ll look at the raw materials required to create lithium ion batteries. Second we’ll look at the battery cell manufacturing. In part 2, we’ll look at the complete battery pack manufacturing, the final Car manufacturing, and end of life recycling of lithium ion batteries.

Different car makers use different cathode chemistries for lithium ion batteries, Tesla uses NCA chemistry, or Nickel, Cobalt, and Aluminium (LiNiCoAlO2). They use this particular chemistry because it offers great energy density, long cycle life, and great charge performance. This makes Tesla’s batteries the absolute top of the line in the EV world. They weigh less, last longer, and power the performance of things like Ludicrous mode.

Tesla’s Batteries have gone through 3 stages: Stage 1 was from 2009-2012 found in the Roadster and Model S. Stage 2 was from 2016-2018 and powered the Model S Gen II, and the Model X. Stage 3 starts with the Model 3 in 2018.

Stage 1 batteries were constructed with 18650 cells, which are 18 mm wide, and 65 mm tall. They had a NCA formulation that required 11kgs of Cobalt in the cathode, per car. They had a pure graphite anode, with no Silicon.

Stage 2 batteries used the same 18650 cells, but reduced the amount of Cobalt required in the cathode from 11 to just 7kg/car. They also introduced a small amount of silicon into their anode.

Stage 3 batteries are new for Tesla, and first shipped with the Model 3. Stage 3 batteries have further reduced the amount of cobalt to just around 4.5kg per vehicle. They also have a hybrid silicon/graphite anode, and while proprietary and unreported, probably higher silicon content than their stage 2 batteries.

Unlike other companies that are planning to sell tens of thousands of EVs each year, Tesla is planning to sell half a million and then a million EVs each year. It's absolutely crucial to understand supply chain fragility when considering that lithium ion battery production is set to soar. Tesla opened Gigafactory 1 in Sparks Nevada, and though it will only be fully completed by 2020, its pumping out batteries, and will only increase its production rate as it nears completion. Tesla has switched from 18650 cells to 21700 cells because it’s an optimized size to maximize energy, with minimal increases in weight, and excellent cost. Voltage is largely unchanged, since its a function of battery chemistry. So the big question here is, why does Tesla use these little battery cells, when they know they’ll need thousands of them? Why not not make custom big batteries, like the ones found on a BMW i3? The i3 uses prismatic batteries, with big custom packs. The Chevy bolt and Leaf use rectangular pouch batteries, which you might think makes more sense since there’s less wasted space.

The i3’s prismatic battery and the Bolts pouch battery have to be specifically made for those cars. They are built to specification, much like your smartphone. Figure out how much space you have left for a battery, then get one custom made. In contrast, the Tesla model 3 uses a new 2170 cell which will be the battery that powers all future tesla models and even their home energy storage solutions.

This flexibility is why Tesla can offer a wide variety of range options. By adding more cell blocks in parallel they can increase range without changing the core voltage of the system. Tesla has a goal of producing batteries at less than $100/kWh.

The Gigafactory is Tesla’s greatest asset, because by investing so heavily into a vertical integration structure, they can control costs and production levels. In contrast General Motors, completely outsources the battery development to LG Chem, who provide complete units ready to drop into their EVs. But if suddenly Honda and Toyota come with contracts to LG Chem, how would that impact GM? Vertical integration for battery manufacture is super costly, but does give Tesla a marked advantage over their competition. In fact, it might be their single biggest advantage.

One question we often get is who’s actually making the battery, Panasonic or Tesla? The answer really is Panasonic. It takes decades to master the chemistry of Batteries, and that’s where Panasonic comes in.

Source: YouTube
